PRESSURE SENSOR

Description

The MPX10DP is a dual-port uncompensated silicon Pressure Sensor for environmental control systems and level indicators. The MPX10 series silicon piezoresistive pressure sensor provides a very accurate and linear voltage output, directly proportional to the applied pressure. This standard uncompensated sensor permits manufacturers to design and add their own external temperature compensation and signal conditioning networks. Compensation techniques are simplified because of the predictability of NXP’s single element strain gauge design.

Features:

• Patented silicon shear stress strain gauge design
• Ratiometric to supply voltage
• Low Cost
• Patented Silicon Shear Stress Strain Gauge Design
• Ratiometric to Supply Voltage
• Differential and Gauge Options
• Durable Epoxy Unibody Element or Thermoplastic (PPS) Surface Mount Package

Specifications:

• Pressure Type: Differential
• Sensitivity, V/P: 3.5mV/kPa
• Operating Pressure : 0kPa ~ 10kPa
• Supply Voltage: 3V – 6V DC
• Sensor Case Style: SIP
• No. of Pins: 4Pins
• Operating Temperature: -40°C to 125°C

Applications:

• Sensing & Instrumentation, Medical, Industrial, Robotics, Automation & Process Control
• Air Movement Control
• Environmental Control Systems
• Level Indicators
